8000 - Premium Commercial Aluminum Full View Garage Door
8000

Premium Aluminum Full View

1/8 inch glass
1/8″ Glass
* 8100 Feature
1/4 inch glass
1/4″ Glass
* 8400 Feature
1/2 inch glass
1/2″ Insulated Glass
* 8500 Feature

The right choice when maximum light and visibility are required. Ideally suited for all residential, commercial, and retail establishments. Choose from a variety of glazing options including glass, acrylic, insulated glass or aluminum panels.

Features

2" thick door sections

Door Sections

Door sections are 2″ thick and consist of extruded aluminum rails and stiles assembled with 5/16″ threaded rods and nuts. Glazing is sealed on all four sides and retained on all four sides with extruded aluminum snap-in beads. The end stiles have a visible width of 3 3/8″. Center stiles have a visible width of 2 3/4″. Top rail has a visible height of 4 1/4″. Bottom rail has a visible height of 4 1/4″ or 7 1/4″ depending on door size and weight.

Combined meeting rails have a visible height of 2 1/2″. Lower meeting rail has an integral reinforcing fin on doors over 12′ 2″ wide (Model 8100) or over 10′ 2″ wide (Models 8400 and 8500).

Glazing

Glazing

Sections can be glazed with 1/8″ glass or acrylic (Model 8100), 1/4″ glass (Model 8400), or 1/2″ insulated glass (Model 8500). Many glazing options are available including tempered glass, tinted glass, low E glass, or laminated safety glass. 0.062″ anodized aluminum panels can be used in any section.

Commercial Aluminum Finish

Finish

All aluminum parts are clear anodized, bronze powder coated, white powder coated or black powder coated. Powder coated in custom colors available.

Rigid Aluminum Retainer

Weatherstrip

Bottom section has a replaceable U type bottom astragal retained by an extruded aluminum retainer. Optional jambs and header weather-stripping is available.

Wind Load

Wind Load

Consult factory for available wind load rated options.

Construction


Aluminum components are clear anodized, bronze powder coated, white powder coated or black powder coated. Powder coated in custom colors on request

4-1/4" Full tubular top rail

Large glass panels allow maximum light and visibility; glass thicknesses from 1/8" to 1/2"

Glass and aluminum panels retained with extruded aluminum snap in bead

Replaceable flexible vinyl bottom weatherstrip

2" thick sections

3-3/8" full tubular end stile

Full tubular bottom rail. 4-1/4" or 7-1/4" depending on door size and weight

2-1/2" combined meeting rails

0.062" aluminum panels finish to match aluminum frame. Aluminum panels can be provided in all sections

2-1/8" integral reinforcing fin on lower meeting rail for doors over 12'-2" wide (Model 8100) or over 10'-2" wide (Models 8400 and 8500)

Color Options

Clear Anodized
White Powder Coated
White Powder Coated
Bronze
Bronze Powder Coated
Black Powder Coated

Size Options

Widths:
Door Widths
Stamp Layout
Up to 9'2"
stamp layout
9'3" to 12'2"
stamp layout
12'3" to 17'2"
Stamp Layout
17'3" to 18'2"
Stamp Layout
18'3" to 20'2"
stamp layout
Heights:
21", 24"

Window Options

1/8
1/8" Glass
1/4" Glass
1/4" Glass
1/2" Insulated Glass
1/2" Insulated Glass

Window Glass Options

Clear
Clear
Satin
Satin
Bronze
Bronze
Gray
Gray
Gray Lite 31
Gray Lite 31
Pattern 62
Pattern 62
